Perforated Cladding

Graphical Perforated Metal Panel Systems

Welcome to the future of architectural design where creativity meets durability. NES Solutions brings your artistic visions to life through precision-cut, perforated metal panels. Whether you're looking to enhance an interior space, clad a building facade, or create dynamic outdoor partitions, our systems allow you to incorporate images, logos, patterns, and custom graphics directly into robust metal surfaces.

Explore the limitless potential of turning metal into a canvas for your designs. From abstract patterns to photorealistic imagery, our perforated metal panels seamlessly integrate your creative ideas with the structural integrity of metal, ensuring a stunning result that lasts for years to come.

Key Features

1. Customizable Design Options

We make it simple to bring your creative vision to life. Whether you have a photo, logo, or unique pattern in mind, our team translates your concept into easy-to-install perforated panels. Perfect for use in interiors and exteriors, our systems can be tailored to create breathtaking installations that reflect your brand or personal aesthetic.

2. Seamless Integration and Continuous Patterns

Achieve a flawless, continuous visual effect with our cutting-edge technology. Our panels are engineered to minimize visible seams, making it possible to create uninterrupted patterns or images across multiple panels. This is particularly useful for large-scale applications, such as building facades, where maintaining design continuity is crucial.

3. Superior Flatness and Durability

Manufactured using premium-grade aluminium, stainless steel, or other durable metals, our panels offer unmatched flatness and structural integrity. Internal rib and stiffeners, ensure exceptional performance and a sleek appearance. Our panels withstand environmental challenges, making them suitable for both indoor and outdoor applications.

4. Larger Panel Sizes for Reduced Installation Time

We offer various panel sizes to fit your project specifications, resulting in fewer seams and quicker installation times. These dimensions are 4x1.5m as standard. 7.5 x 2m is available if required. Whether you're cladding a high-rise or adding artistic elements to an interior wall, our systems ensure efficient and effective results.

5. Curved and Custom Shapes Available

Looking to add dimension to your design? Our panels can be rolled or curved to adapt to almost any architectural concept. Curved panels are an excellent option for achieving smooth, flowing designs that defy traditional, rigid metal structures.

Our Unique Process: Transforming Ideas into Reality

Our streamlined process takes your project from concept to completion in a way that's seamless and stress-free. From selecting your image to final installation, NES Solutions is with you every step of the way.

1. Design Consultation & Project Quoting

We begin by understanding your vision and the unique requirements of your space. Our team gathers all necessary project data and works with you to explore creative possibilities while considering budget, lead times, and technical details.

2. Image Translation and Panel Layout

Whether you provide a photo, logo, or custom pattern, we use our advanced software to transform your image into a pattern of perforations. Our proprietary tools allow us to precisely control the size, spacing, and shape of each perforation, ensuring that your design is beautifully rendered across multiple panels.

3. Shop Drawings & Engineering Review

Once the design is approved, our engineers prepare detailed shop drawings to guide the manufacturing process. Every aspect of the panel system is meticulously planned, from the perforation pattern to attachment systems, ensuring a smooth and flawless installation.

4. Advanced Manufacturing

Using state-of-the-art equipment, we craft your panels with precision. Our manufacturing facility is equipped to handle projects of any scale, producing perforated metal panels that are durable, functional, and beautiful. We pride ourselves on delivering results that meet the highest standards of craftsmanship and quality.

5. Shipping, Delivery, & Installation Support

Our team takes care of all logistics to ensure that your panels arrive on time and in perfect condition. We work closely with trusted installation partners to guarantee a hassle-free installation, whether you choose a standalone panel system or a fully engineered, integrated solution.

Two Unique Design Paths

We offer two primary approaches for creating perforated panel designs: Photoreal and Custom Scripted.

Option 1: Photoreal Process

Bring high-definition images to life in metal with our Photoreal process. Ideal for transforming photos, logos, or complex graphics into a metal canvas, this method uses precision perforations to replicate even the most intricate details.

Steps in the Photoreal Process:

1. Image Selection – Choose your desired image, whether it's a landscape, portrait, or architectural detail.
2. Translation – Using our proprietary software, we transform your image into a perforation pattern, optimizing for panel layout.
3. Perforation – Our manufacturing team uses high-tech machinery to create custom, grid-compatible panels that seamlessly align when installed.

Option 2: Abstract Process

Looking for something more scripted or pattern-based? Our Abstract Process allows for full customization of shapes, perforations, and patterns. This approach offers limitless creativity, making it perfect for designers looking to incorporate geometric designs, custom illustrations, or text-based elements.

Steps in the Abstract Process:

1. Inspiration – Provide your sketches, patterns, or ideas.
2. Artwork Generation – Our team uses specialized software to customize every perforation, making sure the final product matches your creative direction.
3. Fabrication – Precision machinery ensures that the perforations are exactly as designed, creating a cohesive, high-impact panel system.

Materials & Finishes

Our perforated panel systems come in a variety of materials and finishes, each tailored to meet the aesthetic and functional needs of your project:

• Powder-Coated Aluminium: Available in a range of colors, this finish is ideal for vibrant, long-lasting results.
• Anodised Aluminium: NES offer the AnoAli range of 24 colours. These 'live' finishes change colour through the day and have an 80 year expected lifetime.
• Stainless Steel: For a sleek, modern look with incredible durability, stainless steel is a top choice.
• Weathering Steel: Achieve a rustic, industrial aesthetic with our Weathering Steel option, which develops a unique patina over time.
• Custom Finishes: We also offer specialized finishes, such as anodizing, metallic coatings, and custom textures, to make your design truly unique.

Applications

Our perforated metal panel systems are versatile and can be used in a wide range of applications, including:

• Building Facades: Create eye-catching exteriors with panels that integrate seamlessly into your architectural design.
• Interior Partitions: Use perforated panels to divide spaces without losing light and airflow.
• Public Art Installations: Transform urban landscapes with custom art panels that bring life to public spaces.
• Parking Structures: Enhance parking garages with functional, aesthetically pleasing panels that improve ventilation and security.
• Signage and Branding: Incorporate logos or other branding elements into durable, long-lasting metal signs.

Get Started with NES Solutions

If you're ready to elevate your design with custom perforated metal panels, we're here to help. Our team of experts will guide you through the process, from concept to completion, ensuring that your project exceeds your expectations.

Contact us today to learn more or request a quote. Let's turn your vision into a lasting, artistic reality with our Graphical Perforated Metal Panel Systems.

If you would like more information please get in touch with Michael Irwin, Account Manager, by emailing Michael@nes-solutions.co.uk

Rain Screen Cladding Systems will typically have the following benefits:

• Speed of installation
• Wide variety of materials, finishes and colours
• Cost effective solution
• High levels of fire, acoustic and thermal performance
• Highly resistant to all weathers

Max sheet size:

2 meters x 8 meters.

Fixing systems:

• Invisible fix hook on system with pins
• Invisible fix hook on system with hooks
• Dishpan with through face fix
• Interlocking plank
• Bespoke fixing system

This can be for acoustic spandrel panels or architectural cladding.

We offer a range of pre perforated sheets in steel, stainless steel or aluminium. These have a consistant perforation and are fairly commercial. Where the perforations need to be fitted to the panel or there is a variance a custom pattern is created. This is fabricated in 3 main ways:

1) Punched. This is for circular holes. The punch can hold up to 20 differnt tools simultaniously. Our extensive library holds over 3,000 different tools for perforations, dimples, embossing and cutting. The punch is faster than many CNC processes. The use of gang punch tools can allow for as many as 6 holes to be punched simultaniously. Dependant on the "free air flow" of the design and thickness of the material there can be deflection in the sheet (thin material, lots removed). We can roll sheets flat however this is a consideration.

2) Water jet cutting. We can water jet cut at up to 4 meters by 2 meters. This is capable of cutting though 250mm mild steel and 150mm stainless steel. At the cutting edge the accuracy is +/- 0.1mm. The seamless intergration with CAD software allows architects designs to be directly transposed to the sheet. Complete form freedom is possible with an internal diameter of only 2mm. Due to the lack of heat this is ideal for anodised aluminium as it does not damage the structure of the open cell aluminium. Also with Corten the rust "patina" is not effected by the cut border like laser cutting machines. Cement particle board is good as intricate detailing can be achieved without the danger of the sheet cracking or crumbling.

3) CNC routing. We have a number of machines that cut up to 2 meter by 3 meters. CNC Routing is ideal for aluminium composite material (ACM), Corian, Hi-Macs or Polycarbonate. We cannot route steel as it it too hard for the diamond plated carbide drill bits. 3mm diameter drill bit.

For pricing please call 01206 843200 or email Michael Irwin, Account Manager Michael@nes-solutions.co.uk

The more information that can be provided, the faster, more accurate and definitive we can be with our pricing.
Ideally, a full drop box including CAD, .pdf, architectural visualisations and NBS Specifications will be provided.
Typically we like to offer a range of materials, fixing systems and finishes.

These should be broken down into:
• Survey
• Design (drawing up, workshop drawings and structural calculations)
• Manufacture
• Installation.

For jobs under 100 square meters we would generally offer a supply only price. This is due to the project overheads of RAMS, project managers, legal contractual’s, credit insurance, design detailing, site liability insurance etc. We have a list of accredited installation contractors through the UK that we can make available in these instances.
